Fujitsu General America’s AIRSTAGE J- and V-Series are perfect for large residential, and small to mid-size commercial buildings. Extensive lineup from 3 to 24 tons. 58 different indoor units available in 13 styles. Connect up to 63 indoor units per one VRF system. Airstage controls have wired and wireless individual remote controllers, central remote controllers that simultaneously control multiple indoor units, and a variety of converters that link with other systems.
Fujitsu ASUA7TLAV2 Evaporator Indoor Wall Mount Compact 12K BTU,
,
,
Item#:
ASUA14TLAV1
Manufacturer Item:
ASUA14TLAV1
Manufacturer:
FUJITSU
Fujitsu AUUA18TLAV2 Airstage VRF Compact Cassette Indoor Unit Heat Pump 18K
Fujitsu AUUA7TLAV2 Indoor H/P VRF 7K Compact Cassette,
,
,
Fujitsu AOUA96RLBV1 Airstage Condenser Heat Pump Cool 96k BTU 108k BTU Heat 208/3 VAC R410A VRF
- Power source Phase 3-phase
- Voltage 208 / 230 V
- Frequency 60 Hz
- Capacity Cooling 96,000 BTU/h
- 28.1 kW
- Heating 108,000 BTU/h
- 31.7 kW
- Input Power Cooling 7.67 kW
- Heating 7.90 kW
- EER (Non-Ducted/Ducted) Cooling 11.7 / 11.3 Btu/hW
- IEER (Non-Ducted/Ducted) Cooling 23.6 / 20.2 Btu/hW
- COP (Non-Ducted/Ducted) Heating 3.72 / 3.60 W/W
- Air Flow Rate 6,533 CFM (11,100 m/³h)
- Sound Pressure Level*2 Cooling 59 dB(A)
- Heating 59 dB(A)
- Maximum external static pressure 0.32 in.WG (80 Pa)
- Compressor motor output 7.5 kW
- Net Dimensions Height 66-9/16" (1,690 mm)
- Width 36-5/8" (930 mm)
- Depth 30-1/8" (765 mm)
- Net Weight 564 lbs (256 kg)
- Refrigerant Type R410A
- Charge 25.79 lbs (11.70 kg)
- Connection Pipe Diameter Liquid 1/2" (12.70 mm)
- Discharge Gas 7/8" (22.22 mm)
- Operation Range Cooling 5 to 115 °FDB (-15 to 46 °CDB)
- Heating -4 to 70 °FDB (-20 to 21 °CDB),
,
Item#:
AOUA96RLBV1
Manufacturer Item:
AOUA96RLBV1
Manufacturer:
FUJITSU
Fujitsu AUUA12TLAV2 Compact Cassette Indoor Unit VRF 12K BTU 208/230/1,
,
,
Fujitsu ASUA36TLAV2 Indoor H/P VRF 36K Wall Mount,
,
,
Fujitsu Airstage ASUA36TLAV2
Fujitsu ASUA12TLAV2 Indoor Compact Wall Mounted VRK 12K BTU 1 Ton
,
,
,
,
Fujitsu Airstage ASUA12TLAV2
Fujitsu AOUA120RLBV1 Airstage Condenser Heat Pump Cool 120k BTU 135k BTU Heat 208/3 VAC,
,
,
Item#:
AOUA120RLBV1
Manufacturer Item:
AOUA120RLBV1
Manufacturer:
FUJITSU
Fujitsu AOUA120TLBV Airstage Condenser Heat Pump Cool 120k BTU 135k BTU Heat 208/3 VAC R410A VRF
- Power source Phase 3-phase
- Voltage 208 / 230 V
- Frequency 60 Hz
- Capacity Cooling 120,000 BTU/h
- 35.2 kW
- Heating 135,000 BTU/h
- 39.6 kW
- Input Power Cooling 9.75 kW
- Heating 10.11 kW
- EER (Non-Ducted/Ducted) Cooling 11.3 / 11.3 Btu/hW
- IEER (Non-Ducted/Ducted) Cooling 23.8 / 20.1 Btu/hW
- COP (Non-Ducted/Ducted) Heating 3.61 /3.49 W/W
- SCHE (Non-Ducted/Ducted) 25.4 / 25.8 Btu/hW
- Air Flow Rate 7,652 CFM (13,000 m/³h)
- Sound Pressure Level*2 Cooling 61 dB(A)
- Heating 62 dB(A)
- Maximum external static pressure 0.32 in.WG (80 Pa)
- Compressor motor output 11.0 kW
- Net Dimensions Height 66-9/16" (1,690 mm)
- Width 48-13/16" (1,240 mm)
- Depth 30-1/8" (765 mm)
- Net Weight 639 lbs (290 kg)
- Refrigerant Type R410A
- Charge 26.01 lbs (11.8 kg)
- Connection Pipe Diameter Liquid 1/2" (12.70 mm)
- Discharge Gas 3/4" (19.05 mm)
- Suction Gas 1-1/8" (28.58 mm)
- Operation Range Cooling 14 to 115 °FDB (-10 to 46 °CDB)
- Heating -4 to 70 °FDB (-20 to 21 °CDB),
,
Item#:
AOUA120TLBV
Manufacturer Item:
AOUA120TLBV
Manufacturer:
FUJITSU
Fujitsu AOU120RLAVL Cond Heat Pump VRF 10 Ton 230/3,
,
,
Item#:
AOU120RLAVL
Manufacturer Item:
AOU120RLAVL
Manufacturer:
FUJITSU
Fujitsu AOUA72RLBV1 Airstage Condenser Heat Pump Cool 72k BTU 81k BTU Heat 208/3 VAC R410A VRF
- Power source Phase 3-phase
- Voltage 208 / 230 V
- Frequency 60 Hz
- Capacity Cooling 72,000 BTU/h
- 21.1 kW
- Heating 81,000 BTU/h
- 23.7 kW
- Input Power Cooling 5.37 kW
- Heating 5.39 kW
- EER (Non-Ducted/Ducted) Cooling 12.5 / 12.3 Btu/hW
- IEER (Non-Ducted/Ducted) Cooling 24.1 / 20.0 Btu/hW
- COP (Non-Ducted/Ducted) Heating 4.06 / 3.64 W/W
- Air Flow Rate 6,533 CFM (11,100 m/³h)
- Sound Pressure Level*2 Cooling 57 dB(A)
- Heating 58 dB(A)
- MaXimum eXternal static pressure 0.32 in.WG (80 Pa)
- Compressor motor output 7.5 kW
- Net Dimensions Height 66-9/16" (1,690 mm)
- Width 36-5/8" (930 mm)
- Depth 30-1/8" (765 mm)
- Net Weight 564 lbs (256 kg)
- Refrigerant Type R410A
- Charge 25.79 lbs (11.70 kg)
- Connection Pipe Diameter Liquid 1/2" (12.70 mm)
- Discharge Gas 7/8" (22.22 mm)
- Operation Range Cooling 5 to 115 °FDB (-15 to 46 °CDB)
- Heating -4 to 70 °FDB (-20 to 21 °CDB),
,
Item#:
AOUA72RLBV1
Manufacturer Item:
AOUA72RLBV1
Manufacturer:
FUJITSU
